MODULAR MATRIX KVM SWITCH OPTIONS

• The RMT-SC is a compact wired remote that allows one or two touch port selection up to 500 feet away from the switch box.
• Comes with 25 ft. extension cable.
• Extension Cables available to 500 ft. Part number REXT-SR-xx.
• Dimensions(In.) 5.3 x 3.3 x 1.7

• Locate and select computers by name with our On Screen Display (OSD).
• Use keyboard or mouse to operate the switch from menus superimposed onto your monitor.
• Setup SCAN mode and time interval.
• View vital port information.
• Modify the size and position of the On Screen Display.
• OS & software independent.
• Password protection.

• One "back-up" supply for each of the switch's voltage levels instantly replaces lost power in case of failure.
• Replace individual plug-in power supplies from chassis without interfering with switch operation.
• Used in such critical installations as:
  • Military testing of missile launch systems, war games and intelligence.
  • Hospital monitoring systems.
  • University testing facilities.
• Optional. Add "-DRP" to part number.

Keyboard

• Connectors are female 8 pin miniDIN. Adapter cables needed.
• User devices can be PS/2, Sun or Mac.

Monitor

• Connectors are female 15 pin HD.
• A multiscan VGA monitor is required to display the different video outputs from different platforms.
• Crisp & clear 1900x1200 resolution.
• 150 MHz bandwidth.

Box Configuration

• Unit configured via dip switches on front panel for PS/2, Sun or Mac keyboard and mouse.
• User keyboard and mouse must be of the same platform as defined above.
• Must connect to USR-PC not USR-PC-O on Modular Matrix KVM Switches.

Power

• 110 or 220 VAC at 50 or 60Hz.

On Screen Display (OSD)

• Optional, add "O" to part number.
